K1/Max/K1C Linear Rail Gantry Kit Configurator
This is the linear rail gantry configurator for the K1/C-Max series. The Configurator comes with only the hardware kit by default. To allow the Configurator time to work, please click once to Add to Cart.
Estimated 2-3 Week lead time for Printed Parts
Long Shaft High Kraken Temp LDO-42STH60-3004AH(S37) are now available as an option for the motors!
We as a community have finally found the holy grail of K1 print quality and it is quite impressive. With the help of the D3vil Designs community, Bootycall Jones has finally reached what we think is the best gantry design for your K1, K1C, and K1Max.
This linear rail system design utilizes new stepper motors, a linear rail, and a whole new printed part gantry to fix issues with heavy vibration, mechanical binding, and poor belt alignment.
Install Video by Covenant Custom!
DOES NOT SUPPORT LIDAR
Additionally, NEW POWGE EPDM, Gates Reinforced and EPDM(High Temp) belts are available for purchase if you want to fully upgrade your gantry. 6mm - (3Meters K1, 4Meters K1 Max) 9mm will not fit
|
2
|
M3x20 |
| 8 | M3X6 SHCS |
| 6 | M3x25 FHCS |
| 4 | M3x40 FHCS |
| 16 | M3x6 FHCS |
| 2 | M3x6 BHCS |
| 18 | M3 Heat Set Inserts (M3x4.6x5.7) |
| 17 | M3 Heat Set Inserts (M3x5x4) |
| 2 | M2 Heat Set Inserts (M2x3.6x4) |
| 8 | M3 Thin Square Nut |
| 24 | F623 2RS Abec 7 Bearings |
| 4 | M6x6 Set Screw |
| 16 | M3x7x0.5mm Precision Shim |
| 2 | 5mm Bore GT2 Pulley 20T |
