Edit 2 (10/18/24): Long Shaft High Kraken Temp LDO-42STH60-3004AH(S37) +$99USD are now included as an option for the motors! They are currently on preorder and will start shipping in November.
Edit 1 (9/3/24): Updated links to the LRGK Configurator.
Do you have a Creality K1, K1C, or K1 Max printer and just want to make it better? Improve your Creality printer experience with the new upgrade – the Linear Rail Gantry Kit designed by Bootycall Jones – available for preorder TODAY!
With the stock gantry of the Creality K1 printer series, users quickly discovered issues with the x-axis rod. These issues caused heavier vibration, which led to print flaws, such as VFAs, or vertical fine artifacts – the little ripples found on the surface of a print. Fortunately, Bootycall Jones developed a new linear rail gantry design that seeks to improve the Creality K1 printer series experience for all users. Created to bring your 3D prints to perfection, this mod has the added bonus of making your Creality K1 series printer quieter, faster, and more reliable. With the help from the D3vil Design community, this linear rail gantry mod was tested and has been certified fresh.
The new and improved design includes new stepper motors, a linear rail, and a whole new printed part gantry to fix issues with the heavy vibration, mechanical binding, and poor belt alignment. After many months, this gantry design has been finalized and is now ready to be preordered as a kit only found at PeeDee3D.com at the starting price of $120.99.
This preorder won't last long. Be one of the first people to massively upgrade their Creality K1 series experience, so order your Linear Rail Gantry Kit while you can!
Curious about what's included in this purchase? Check out the Full Kit as listed below:
- ASA-GF printed parts included. Optional Upgrade to ABS-GF25 (Black/Grey are Base Colors).
- LDO-42STH48-2504AC (S35) available for long shaft configuration.
- 10ml EP1 Grease
- M3 Screws
- M2 & M3 Heat Set Inserts
- M3 square nuts
- F623 2RS Abec 7 Bearings
- 16T 3mm Bore Idler
- M6 Screws
- M3 Precision Shims
- 5mm Bore GT2 Pulley 20T
- LDO 2504 Stepper Motor
- Youmetong Preloaded 320mm MGN12H (K1/K1C) OR Youmetong Preloaded 400mm MGN12H (K1 Max)
***Additionally, Gates Reinforced and EDPM(High Temp) belts are available for purchase if you want to fully upgrade your gantry. And in the near future, the hardware, printed parts, and rails will be listed separately for purchase. Look out for that update by signing up for our newsletter!
Again, thanks to Bootycall Jones (and to the testers of the D3vil Design community) for this impressive upgrade. Make sure you also support him on Makerworld.com here and on Ko-fi here.
You can also find the Linear Rail Guide and Documentation here.
Finally, shipping is expected to begin mid-June at the latest.
Please let us know if you have any questions regarding this product. And as always…
Happy Printing!
PeeDee3D
